  • Sale
  • $179.95
  • 1 available
  • Axis Communications 0764-001-01 AXIS M7011 1-Channel Video Encoder
  • The single-channel AXIS M7011 Video Encoder offers easy and cost-effective integration of analog CCTV cameras into an IP-based video surveillance system. It comes with Zipstream with support for H.264 video compression, which drastically reduces bandwidth and storage requirements without compromising image quality. Powered with PoE, it needs just one Ethernet cable for both data and power. The video encoder also features a microSD card slot for edge storage. AXIS M7011 is a simple, yet powerful, compact video encoder offered at an attractive price.
  • Features:
    • Highly compact design
    • Zipstream with support for H.264
    • Edge storage
    • Power over Ethernet (PoE)
    • RS-485/RS422 PTZ control
  • Specifications:
    • Video:
      • Video Compression: H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High profile Motion JPEG
      • Resolution: 176x144/176x120 (PAL/NTSC) to 720x576/720x480 (PAL/NTSC)
      • Frame Rate: 25/30fps (PAL/NTSC) in all resolutions
      • Video Streaming: Multiple, individually configurable streams in H.264 and Motion JPEG, Axis Zipstream technology in H.264, Controllable frame rate and bandwidth
      • Image Settings: Compression, color, brightness, contrast, rotation: 0°, 90°, 180°, 270°, aspect ratio correction, mirroring of images, text and image overlay, privacy mask, enhanced deinterlace filter, video termination, anti-aliasing, temporal noise filtering, sharpness, noise reduction, local enhancement
    • Network:
      • Security: Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, Digest authentication, User access log, centralized certificate management
      • Supported Protocols: IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
    • System Integration:
      • Application Programming Interface: Open API for software integration, including VAPIX and AXIS Camera Application Platform; One-click cloud connection, ONVIF Profile S and ONVIF Profile G
      • Analytics: Included AXIS Video Motion Detection, active tampering alarm, Support for AXIS Camera Application Platform enabling installation of third-party applications, see axis.com/acap
      • Event Triggers: Analytics, video loss, edge storage events
      • Event Actions:
        • File upload: FTP, SFTP, HTTP, HTTPS network share and email
        • Notification: email, HTTP, HTTPS and TCP
        • External output activation
        • Pre- and post-alarm video buffering
        • PTZ preset
        • Status LED
      • Data Streaming: Event data
    • General:
      • Casing:
        • Material: PC+ABS CX7240
        • Color: Dark Blue 2T3D091 STD
      • Sustainability: PVC free
      • Memory: 256 MB RAM, 256 MB Flash, Battery backed-up real-time clock
      • Power: Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 1
      • Connectors:
        • Analog composite video BNC input
        • RJ45 10BaseT/100BaseTX PoE
        • RS485/RS422
      • Storage:
        • Support for microSD/microSDHC/microSDXC card
        • Support for SD card encryption
        • Support for recording to network-attached storage (NAS)
      • Operating Conditions: 0 °C to 50 °C (32 °F to 122 °F), Humidity 10–85% RH (non-condensing)
      • Storage Conditions: -40 °C to 65 °C (-40 °F to 149 °F)
      • Approvals:
        • EMC
          • EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024,
          • EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A+B,
          • ICES-003 Class B, VCCI Class B, RCM AS/NZS CISPR 22 Class B,
          • KCC KN22 Class B, KN24
        • Safety
          • IEC/EN/UL 60950-1
        • Network
          • NIST SP500-267
      • Dimensions: 90 X 29 X 38 mm (3.5 X 1.1 X 1.5 in)
      • Weight: 71 g (0.16 lb)
      • Video Management Software: AXIS Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available at axis.com/vms
      • Languages: English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese
  • Manufacturer: Axis Communications
  • Model Number: AXIS M7011
  • Part Number: 0764-001-01
  • Also Known As: 0764-001
  • Condition: In Stock, Ready to Ship! This unit is in excellent physical condition. See Photos. Guaranteed in good working order and covered by a 14 day return policy. This listing is only for what is shown in the photos. No other parts or pieces are included.
